Customized Cheap Price G4 Primary Panel Pleated Cardboard Frame Air Filter
Product Information
A pleated air filter is made from a sheet of polyester, paper, or cotton folded into pleats to increase the entire surface area. This allows the filter to trap more airborne particles such as dust, dirt, and hair (from pets and humans), which could otherwise damage your furnace's blower fan and clog the AC coils.
The Pleated Filter is designed for longer life with reduced maintenance costs. All filters are designed for easy installation in existing HVAC systems. Performs well as the primary filter or as a prefilter to a more efficient filter.
Product features
Surface mesh used by rust treatment process, good appearance and durable
Large media area
Great sealing property
Large dust holding capacity
100% Factory inspection
Long life-span
Distortion-free
Application:
The office, shopping mall, stadium, and the airport, general industrial workshop, clean room of air distribution system on the filter.
OEM:
Customized design is available.
W*H*D(Inch) | W*H*D(Inch) | Area(m2) | Airflow(CMH) | Initial pressure(pa) | Airflow(CMH) | Initial pressure(pa) |
12*24*1 | 290*592*21 | 0.28 | 930 | 85 | 1550 | 135 |
20*20*1 | 492*492*21 | 0.39 | 1330 | 2200 | ||
20*24*1 | 492*592*21 | 0.47 | 1600 | 2650 | ||
20*25*1 | 492*620*21 | 0.49 | 1660 | 2760 | ||
24*24*1 | 592*592*21 | 0.56 | 1900 | 3175 | ||
12*24*2 | 492*492*46 | 0.46 | 930 | 55 | 1550 | 85 |
20*20*2 | 492*492*46 | 0.61 | 1330 | 220 | ||
20*24*2 | 492*592*46 | 0.72 | 1600 | 2650 | ||
20*25*2 | 492*620*46 | 0.76 | 1660 | 2760 | ||
24*24*2 | 592*592*46 | 0.92 | 1900 | 3175 | ||
12*24*4 | 290*592*96 | 0.84 | 930 | 45 | 1550 | 70 |
20*20*4 | 492*492*96 | 1.17 | 1330 | 2200 | ||
20*24*4 | 492*592*96 | 1.40 | 1600 | 2650 | ||
20*25*4 | 492*620*96 | 1.46 | 1660 | 2760 | ||
24*24*4 | 592*592*96 | 1.68 | 1900 | 3175 |
![]() |
